Overview. Dimensions. Ø160 x 32.7 mm. (Ø6.3 x 1.3""). WiFi Standard. WiFi 5. Spatial Streams. 6. Coverage Area. 140 m² (1,500 ft²). Max. Client Count. 200+. Uplink. GbE. Mounting Locations. Ceiling, wall. Mounting Plate. Lite mounting plate (Included). Power Method. PoE. Performance. MIMO. 5 GHz. 4 x 4 (DL MU-MIMO). 2.4 GHz. 2 x 2 (DL MU-MIMO). Max. Data Rate. 5 GHz. 1.7 Gbps (BW80). 2.4 GHz. 300 Mbps (BW40). Antenna Gain. 5 GHz. 3 dBi. 2.4 GHz. 2.8 dBi. Max. TX Power. 5 GHz. 26 dBm. 2.4 GHz. 23 dBm. Max. BSSIDs. 8 per Radio. Supported Data Rates. 802.11ac (WiFi 5). 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80). 58 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 160). 802.11n. 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40). Features. Wireless Meshing. Yes. Band Steering. Yes. 802.11v BSS Transition Management. Yes. 802.11r Fast Roaming. Yes. 802.11k Radio Resource Management (RRM). Yes. Advanced Radio Management. Yes. Passpoint (Hotspot 2.0). Yes. Captive Hotspot Portal. Custom Branding Landing Page. Yes. Voucher Authentication. Yes. Payment-Based Authentication. Yes. External Portal Server Support. Yes. Password Authentication. Yes. Guest Network Isolation. Yes. Private Pre-Shared Key (PPSK). Yes. WiFi Speed Limiting. Yes. Client Device Isolation. Yes. WiFi Schedules. Yes. RADIUS over TLS (RadSec). Yes. Dynamic RADIUS-assigned VLAN. Yes. Hardware. Max. Power Consumption. 10.5W. Includes PoE Adapter. Yes. Supported Voltage Range. 44—57V DC. Networking Interface. (1) GbE RJ45 port. Weight. Device: 300 g (10.6 oz). With mount: 315 g (11.1 oz). Management. Ethernet. LEDs. System. Status. Channel Bandwidth. HT 20/40, VHT 20/40/80/160 (MHz). Certifications. CE, FCC, IC, cULus. Operating Frequency. US/CA:. 2400 - 2472 MHz. U-NII-1: 5150 - 5250 MHz. U-NII-2A: 5250 - 5350 MHz. U-NII-2C: 5470 - 5725 MHz. U-NII-3: 5725 - 5850 MHz. . Worldwide:. 2400 - 2483.5 MHz. 5150 - 5725 MHz. Ambient Operating Temperature. -10 to 70º C (14 to 158º F). Ambient Operating Humidity. 5 to 95% noncondensing
