Image Sensor Sony 4K, 8.42M pixel
Video Outputs (USB 3.0) H.264/MJPEG up to 2160p@30fps,
YUV up to 1080p@30fps
Video Outputs (USB 2.0) H.264/MJPEG up to 1080p@30fps
Video Outputs (HDMI) H.264/MJPEG up to 2160@30fps
Video Outputs (IP) H.264/MJPEG up to 2160p@30fps (First Stream)
H.264/MJEPG up to 720p@30fps (Second Stream)
Optical Zoom 12x
Digital Zoom 3x
Field of View (FOV) DFOV 90°/ HFOV 80°/ VFOV 49.2°
Lens Focal Length 4.8 mm ~ 57.8 mm
Lens Aperture (F#) 1.8 ~ 3.6
Motorized Pan & Tilt Pan: ±170°, Tilt: ±90°
Preset Number 10 Presets via IR Yes Remote, 128 Presets via RS232
Image Flip and Image Mirror Yes
Power Supply DC in 12V, 2A / POE+ in (Max 25W)
Power Consumption ? 22W
